Introducing

CubiSens™ XT1

Transforming Cold Chain Visibility

XT1 Vial
XT1 App

Redefining Cold Chain Monitoring

Fragmented temperature monitoring. Data aggregation challenges. Incomplete tracking of shipments at the “first mile” and “last mile.” These are serious problems in the cold chain that result in the disqualification of millions of doses of biologic drugs annually.

Enter the CubiSens™ XT1, a small, wireless family of smart sensors and a revolutionary solution for monitoring temperature and tracing products, such as food and doses of biologics, at the item level. The XT1 can be attached to both large shipments and individual items to provide the temperature history for a product’s lifetime.

Enabling Item-Level Tracking

Use the XT1 to prove originality of product and take action to prevent the disqualification of shipments. The XT1 is small enough to be affixed to individual boxes, vials, and syringes, and can operate in sensing mode for up to 3 years. Pharmaceutical manufacturers, wholesalers, and “3PLs” now have complete visibility of temperature history throughout the supply chain.

Smart, Fine-Grain Sensing, Superior Results

The XT1 is a comprehensive tracking solution that is both easy to use and deploy. Use the XT1 as a digital record of proof of regulatory compliance. With the XT1, users can mitigate the threat of lost revenue.

Track

Wirelessly track the temperature of individual and high-value, high-risk, products, such as biologics, for a product’s lifetime.

Trace

Monitor biopharmaceuticals from the “first mile” to the “last mile” of the cold chain to ensure quality and compliance.

Prevent

Coming soon.
Receive real-time status and advanced multi-level excursion alerts to take actions and drive process improvement.

CubiSens™ XT1 Product Lineup

The XT1 product lineup features a new generation of tags with ultra-small form factor and battery life. Say “goodbye” to bulky tracking devices.

Up to 3-Year Operation

Superior Battery Life and Data Storage

±0.3°C Accuracy

Built for Integrity

Ultra-Small & Item-Level Ready

As small as 16mm ø (CubiSens™ XT1 NFC)

Powered by Patented Technology

The XT1 is based on years of research on ultra-low-power circuits, and it was born out of the University of Michigan’s Michigan Integrated Circuits Lab. The XT1 features CubeWorks’ patented CubiSens™ technology, resulting in a next-generation IoT sensor that is completely wireless and 100x smaller than conventional data loggers.

XTcloud

Cloud Platform for Data Management and Analytics

XTcloud™ offers a comprehensive solution for managing and analyzing data generated by the XT1.
Coming soon: real time data and AI-based analytics and predictions.

Technical Specifications

CubiSens™ XT1 NFC
NOW AVAILABLE
CubiSens™ XT1 Max
NOW AVAILABLE
CubiSens™ XT1 Max Dry Ice
COMING SOON
Dimensions 16mm ø x 5mm49mm x 49mm x 7mm49mm x 49mm x 7mm
Weight1.25g17.7g17.7g
Battery Life3 Years2 YearsUp to 1 Year
Temperature Accuracy±0.3°C ±0.3°C±0.3°C
Temperature Resolution0.1°C0.1°C0.1°C
Operation Temperature-40ºC to 65ºC-40ºC to 65ºC-80ºC to 65ºC
Calibration MethodIndividual CalibrationIndividual CalibrationIndividual Calibration
Wireless ConnectionSmartphone / NFC InterfaceSmartphone / NFC InterfaceSmartphone / NFC Interface
DOWNLOAD DATASHEETDOWNLOAD DATASHEETDOWNLOAD DATASHEET

Ready To Explore the XT1?
